VIDEO
Input: 16CH AHD Standard BNC + 8CH IP (Over Network)
Output: HDMI, VGA (800×600, 1024×768, 1280×1024), CVBS
RECORDING
16CH AHD/Analogue + 8CH IP
AHD: 1080P
FPS: 200 (PAL) / 240 (NTSC)
Resolution: 1920×1080 (PAL/NTSC)
AHD: 720P
FPS: 400 (PAL) / 480 (NTSC)
Resolution: 1280×720 (PAL/NTSC)
Analogue: 960H
FPS: 400 (PAL) / 480 (NTSC)
Resolution: 960×575 (PAL) / 960×480 (NTSC)
IP: 1080P
FPS: 200 (PAL) / 240 (NTSC)
Resolution: 1920×1080 (PAL/NTSC)
(*3MP, FPS: 150 (PAL) / 180 (NTSC))
PLAYBACK
8 Channel Simultaneously
AUDIO
Input: 4 Channel (RCA)
Output: 1 Channel (RCA)
2 Way audio
STORAGE
2 x SATA (Up to 4TB)
NETWORK
RJ-45: 100Mbps
ALARM
Input: 4 Channel
Output: 1 Channel
USB PORT
2 x USB2.0
PTZ / KEYBOARD
1 x RS485
Protocol: Pelco DP/Samsung/Visca (IP Over ONVIF)
